ThinkPad T14 Gen 5 (AMD)
Type Model : 21MC0069ID

PERFORMANCE
Processor AMD Ryzen 5 PRO 8540U (6C / 12T, 3.2 / 4.9GHz, 6MB L2 / 16MB L3)
AI PC Category Non-AI PC
NPU None
Graphics Integrated AMD Radeon 740M Graphics
Chipset AMD SoC Platform
Memory 1x 16GB SO-DIMM DDR5-5600
Memory Slots Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory Up to 64GB DDR5-5600
Storage 1TB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0
Storage Support One drive, up to 2TB M.2 2280 SSD
Storage Slot One M.2 2280 PCIe 4.0 x4 slot
Card Reader None
Optical None
Audio Chip High Definition (HD) Audio, Realtek ALC3287 codec
Speakers Stereo speakers, 2W x2, Dolby Audio
Camera 5.0MP + IR Discrete with Privacy Shutter
Microphone 2x, 360°
Battery Integrated 52.5Wh
Power Adapter 65W USB-C Slim (3-pin)

DESIGN
Display 14" WUXGA (1920x1200) IPS 400nits Anti-glare, 100% sRGB, 60Hz, Low Power
Touchscreen None
Keyboard Backlit, English
Case Color Black
Case Material PC + 20% CF (Top), PC + 20% CF (Bottom)
Pen Pen Not Supported
Dimensions (WxDxH) 315.9 x 223.7 x 17.7 mm (12.44 x 8.81 x 0.7 inches)
Weight Starting at 1.39 kg (3.06 lbs)

SOFTWARE
Operating System Windows 11 Pro, English
Bundled Software None

CONNECTIVITY
Ethernet 100/1000M (RJ-45)
WLAN + Bluetooth Qualcomm Wi-Fi 6E NFA725A, 802.11ax 2x2 + BT5.3
WWAN Non-WWAN
SIM Card None
NFC None
Standard Ports "1x USB-A (USB 5Gbps / USB 3.2 Gen 1)
1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On
2x USB-C (Thunderbolt 4 / USB4 40Gbps), with USB PD 3.0 and DisplayPort 2.1
1x HDMI 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)"
Optional Ports (configured) None
Docking "Various docking solutions supported via Thunderbolt.

SECURITY & PRIVACY
Smart Card Reader None
Security Chip Discrete TPM 2.0 Enabled
Fingerprint Reader Touch Style, Match-on-Chip, Integrated in Power Button
Physical Locks Kensington Nano Security Slot, 2.5 x 6 mm
Other Security "Camera privacy shutter (camera models)
Ultrasonic Human Presence Detection (IR camera models)
IR camera for Windows Hello (facial recognition)"

MANAGEABILITY
System Management DASH
SERVICE
Base Warranty 1-year, Courier or Carry-in
Included Upgrade 3Y Premier Support Upgrade from 1Y Courier/Carry-in

ACCESSORIES
Bundled Accessories None

CERTIFICATIONS
Green Certifications "ENERGY STAR 8.0
EPEAT Gold Registered
ErP Lot 6/26
RoHS compliant
TCO Certified 10.0"
Other Certifications Eyesafe Certified 2.0
Mil-Spec Test MIL-STD-810H military test passed
